Industrial X-ray Apparatus Applications in Hydrogen Energy Field
I. X-ray Apparatus Technical Principles
· Technical Principle: Utilizing the difference in absorption of X-rays by different materials when penetrating testing object, it detects internal structures through X-ray detectors. Suitable for flaw detection such as pores, cracks, and inclusions in hydrogen storage tanks and pipeline welds.
II. Applications in the Hydrogen Energy Industry
1. Inspection of Hydrogen Storage Containers/tanks
· Used for detecting defects such as pores, layering, and fiber fractures inside composite material hydrogen storage tanks to ensure safety.
2. Welding of Pipes and Valves
· Detecting issues such as incomplete penetration and slag inclusion in the weld seams of hydrogen transportation pipelines to prevent hydrogen embrittlement and leakage.
3. Fuel Cell Components
· Conducting non-destructive testing on the sealing structures of bipolar plates/electrochemical stacks to ensure the stability of electrochemical reactions.
III. Recommended Equipment
1.Portable X-ray digital radiography(DR) inspection system
· Portable X-ray unit: Suitable for on-site inspection, capable of supporting field operations. SF6 gas insulation, automatic fault retrieval, 100% duty cycle high-resolution image quality with high-frequency constant voltage, long life span metal ceramic X-ray tubes, and stable reliability.
· Flat-panel X-ray detector:
2. High-precision Industrial CT(computed tomography)inspection System
· Industrial CT inspection System: Industrial CT (standard CT, micro-focus CT, high-energy CT), capable of conducting three-dimensional scanning and reverse engineering analysis of hydrogen energy products, with detection accuracy reaching micrometer level.
· Industrial X-ray Digital Imaging System: pipe/boiler/pressure vessel, industrial DR digital imaging inspection system, with efficient intelligent automated flaw detection method(ADR automatic detection recognition software), offers a more intuitive inspection result.
IV. Technical Advantages
· Non-contact detection, capable of retaining defect image records (such as x-ray film or 2D/3D digital X-ray images).
· High sensitivity, capable of identifying defects as small as micrometers level when using high-end configurations.
Cutting-edge Technologies
· Intelligent Upgrade: Integrating AI image recognition technology, it automatically analyzes the types and grades of defects.
· Lightweight Design: Developing portable devices with lower weight and higher resolution to meet the distributed detection requirements of hydrogen energy applications.
