Raysov RSO30 series diffractometer orientation instrument series is specifically designed for semiconductor, photovoltaic, and precision manufacturing industries to provide reliable lattice orientation measurement solutions. The system adopts single diffraction/double diffraction technology, enabling rapid and precise crystal angle measurement, providing key data support for subsequent cutting, grinding, and other processes. With a high-sensitivity detection system and stable mechanical structure, orientation Instrument can accurately measure various samples such as crystal ingots, bars, and wafers.

Product Description

x ray diffractometer
XDR X-ray Diffractometer orientation instrument
Raysov RSO30 series diffractometer orientation instrument series is specifically designed for semiconductor, photovoltaic, and precision manufacturing industries to provide reliable lattice orientation measurement solutions. The system adopts single diffraction/double diffraction technology, enabling rapid and precise crystal angle measurement, providing key data support for subsequent cutting, grinding, and other processes. With a high-sensitivity detection system and stable mechanical structure, orientation Instrument can accurately measure various samples such as crystal ingots, bars, and wafers. The equipment is designed in a modular manner and supports both manual and semi-automatic operation modes. It can maintain excellent performance even in harsh production environments and meets the detection requirements of different process stages.
Orientation systemDual X-ray Diffractometer measurement system (X-axis automatic positioning), arranged at 90° angles. ss parameters.
DetectorHigh-sensitivity scintillation detector
Orientation accuracy/bonding AngleEquipment parameter memory, no need for repeated calibration.
Automation functionFully automatic orientation, measurement, rotation, bonding. Supports one-click operation.
crystal bar orientationInfrared positioning + laser automatic positioning NOTCH/OF surface system.
Mechanical controlDual-axis mechanical hand rotates to correct angles, motor direct drive.
Bonding pressure controlAdjustable pressure range: 50-200N, real-time monitoring.
Bonding methodSelf-automated adhesive application, supports small-range correction of resin strip position.
Base compatibilityCompatible with wire-cutting machine material holder (customizable), supports multi-crystal bar splicing (gap can be set).
Operation interfaceSelectable touch screen, anti-mistake operation design.
Memory functionEquipment parameter memory, no need for repeated calibration.
Real-time monitoringReal-time display of X/Y-axis deviation angle, bonding pressure, glue position.
False alarmAutomatic alarm for operation errors or over-limit.
Data managementInternal database stores process parameters, supports data upload, barcode traceability.
Remote supportRemote data analysis and fault diagnosis.
Extended optionsAutomatic loading and unloading device, multi-devices synchronized operation. automatic).
Automatic adhesive application device (glue mixing - adhesive application fully
SECS/GEM or TCP/IP communication protocol, connects to MES/automated factory
Quick-curing adhesive module, improves production cycle.
Special design of material holder, Process parameters deep adaptation
